Photoshop Brushes

I wondered what would happen if I used every brush in one image.  I guess this is the answer.
If you are a long-time Photoshop user, this will be a boring post for you. But if you recently made or are making the switch, then it might help. In order to make the transition to Photoshop, I had to change how I think about and use brushes. These are the categories that I find useful for everyday painting:
Drawing: brushes that work well at small scales and for details
Gradient: brushes that are good for making a smooth shift in colors with minimal "banding"
Edge: brushes that can easily create an edge
Blending: smudge tools that help smooth banding or introduce distortion to smooth areas
Texture: brushes that create strong textures
Feature: brushes used as a shortcut to create specific things (ie. trees, chains, windows, etc.)
I'll talk about each of these separately, except feature brushes, since they are so highly customized. I've included a link at the bottom with the brushes I used in this post. Copy the file into the appropriate photoshop\presets\tools folder and you can access it from your Tool Presets window/menu. I like tool presets because they contain all of a tool's information (not just stuff in the brush menu) and can be used for things like the smudge tool.


Drawing Brushes:
This conte brush is from Simini Blocker's brush set. Thanks Simini!
Photoshop does a very poor job with brush scaling. Brush dabs made at a certain size look mushy when scaled up or down very far. This is especially problematic with brushes you want to use for details, so you need brushes suited to that purpose. None of my drawing brushes are exciting, but they get the job done.


Gradient Brushes:
Jason's Nice Brush from Jason Kim, Rounded Square modified from Tom Scholes, Spatter Soft from Chris Wahl, and Oil Brush from Blur's Goodbrush set
Photoshop's airbrush does a good job with smooth gradients, but if you want something with just a little more meat and interest, there are a variety of brushes that allow you to go from fully transparent to fully opaque with very little banding (sudden jumps in color/value). Turn down the opacity enough and lots of brushes can work fairly well for this, but sometimes it's nice to have a brush you can control to full opacity using pressure. The most important brush here is the Rounded Airbrush. It has a falloff that matches the falloff of light on a rounded surface, and it feels just like my modified 2b Pencil brush from Painter.  I created the Rounded Eraser from the same dab (also in the tools below) and it works just like the Eraser brush from Painter (try it and you will see why it is awesome).


Edge Brushes:
Square Chalk from Blur's Goodbrush set, link above
I like brushes that allow me to get a strong edge, and with a few exceptions, gradient brushes are bad at that. Painter had various brushes that could do both, but Photoshop's brush engine seems to resist giving me that same seamless control. My versions of the Captured bristle and the Rounded Square can be used both for gradients and for edges, if not perfectly. This Captured Bristle, by the way, is based off my favorite brush from Painter, the Captured Bristle Acrylic. It's not as good, but this brush makes me miss it less. These hard-edged brushes become surprisingly useful when paired with blenders, the next category.


Blending Brushes:

Some of these have been modified from other sets, but I don't remember well enough to track them down.  Sorry.
Sometimes I just can't avoid banding, or sometimes I don't want to worry about smoothness while I lay down color. Other times I want to introduce texture or variation to the image using the colors already there. Photoshop's smudge tool is pretty good for this, but is very limited. I assume the Adobe team turned off the texture and dual brush controls for speed, but missing those controls means you have a limited number of stroke types. If you are used to the control of Painter's brushes then the smudge tool is an extra step, but you can get some nice effects with it anyway. My favorite of these is Smudge Nice, and I use it for almost everything.


Texture Brushes:

Dappled Texture from Ben Simonsen, Heavy, Paint Texture, and Spatter Airbrush from Blur's Goodbrush, Scribbles from Chris Wahl, Tree brush from Jaime Jones, I think
I hardly ever use these for painting, only for adding interest and variety. These brushes don't have very good edge control. This requires either accepting the loss of control, or using selections or some other method to add boundaries to your paint area. Dual Brush combinations can add some edge control, but may introduce other issues. I do like how brushes like these can quickly hide the digital feel you sometimes struggle to get away from in Photoshop.

Download my tool presets here (installation instructions above). I'm going to do another post later with my CS6 brushes, which include some more interesting options.

47 comments:

  1. That is too awesome. I've been transitioning over to PS for more art/illustration and have been struggling to create my own library of presets. Thanks! I've been enjoying your posts for a long time.

    ReplyDelete
  2. I have been a long time user of photoshop, but mainly for photo and image editing. I'm interested in moving into the more artistic side of it and this is very helpful! Thank you for posting this!

    ReplyDelete
  3. Amazing post, Thanks Sam. I've been trying to find a use for smudge, but I never really knew how to customize it like this before.

    ReplyDelete
  4. Thank you very much! Excellent tool presets!

    ReplyDelete
  5. Thankyou great post sums it up nicely :)

    ReplyDelete
  6. Sam, this may have an easy explanation, but I get confused with the dual brush and why I can't see what two brushes a dual brush is created from. Is there a way to tell?

    ReplyDelete
  7. This is so useful, Sam! Thanks so much!

    ReplyDelete
  8. Dan: I'm planning a post to go into more specifics on the smudge tool. Stay tuned!

    Mark: The interface of the PS brush engine is one of its strengths, but the dual brush interface is one of the weakest points within that. The current brush preset (the one your started with) forms the outside stroke, and the brush you select within the dual brush window adds texture/variation within that stroke. Play around with the blending method above for some interesting results!

    Thanks everyone else!

    ReplyDelete
  9. Thanks Sam! I'm consistently amazed by your talent.

    ReplyDelete
  10. Hi Sam ,

    Thanks a lot for to share your tools with us , I appreciate that.
    About photoshop , I find it very plastic , and I feel very confortable in Painter , but I reconiza that Photoshop is more complete that Painter.
    If you miss painter , I´ve found this plugin for photoshop , it´s the Painter color wheel:

    http://nerdchallenge.com/lenwhite/LenWhite.com/LenWhite.com/Entries/2012/9/16_PW_CS6.html

    ReplyDelete
  11. Excellent post, I can compliment your idea of ​​blending? I use the "Mixer Brush Tool" on brush tab, I uncheck "Load After each Brush Stroke".
    Also set a shortcut "N" key. Lalala I'm dancing with B, NBB, NNN, bb ...

    ReplyDelete
  12. While doing your course I forced myself to use the Painter, then tried to find a way to simulate the painter Blends. I particularly do not like the result of blend tool, I think the Mixer brush tool closer to the painter results.

    Course everyone finds the best way to reach your quality:)

    ReplyDelete
  13. Thank you so much you are amazing !!!

    ReplyDelete
  14. Jose Ramos: I agree about the plasticity of Photoshop. One of the things I do not like about it is that you have to take extra steps to remove that feeling. I do like the color wheel better than Photoshop's horrid color picker.

    Flavio: Maybe once I'm really accustomed to Photoshop I'll take a look at the mixer brushes again. I can't stand them right now. Maybe my experience with the subtlety of Painter makes Photoshop's attempt feel ham-handed---like finger-painting when you're used to a brush. Thanks for the tip on the re-load setting/keystroke!

    ReplyDelete
  15. Thanks a ton, Sam. I have spent many hours customizing PS brushes but never been very happy with them.

    ReplyDelete
  16. Thank you so much !
    You are my hero, you change my life dude !

    ReplyDelete
  17. Thanks Sam for your answer.You have uploaded your brushes , could you do the same with you r spacework in photoshop?

    ReplyDelete
  18. Jose: You mean my workspace? I don't really customize my workspace in photoshop. Just the color wheel and I keep the brush tab handy and my tool presets open.

    ReplyDelete
  19. Marci8:16 AM

    These are really great. I'm a long time Photoshop user, but I can never seem to get quite the brush look I want. Thanks so much!!!

    ReplyDelete
  20. Yikes! 6.66 MB!
    A supernatural talent, indeed, but apparently the DEVIL is truly in your details, sir! ;)

    Can't thank you enough for sharing these awesome resources. I'm always impressed how generous the truly great artists are with their knowledge and resources.

    Really hope to be able to afford your Schoolism class someday (as long as it doesn't cost $666).

    All the best and God bless, Mr. Nielson!

    ReplyDelete
  21. Thank you so much! Thanks god I kept reading! :) I didn't know about the tools and I feel now as a kid with new shoes haha
    You rock Sir

    ReplyDelete
  22. thank you sam, that's defenitly the best brush pack I have found in years. I have a question thoughm and pardon my ignorance. Is there a way to use these presets with the eraser tool ? They just disapear when I choose the erase....

    ReplyDelete
  23. This comment has been removed by the author.

    ReplyDelete
  24. This comment has been removed by the author.

    ReplyDelete
  25. Bret: I prefer to do the alternate calculation for MB. :)

    Yaniv: After you select a tool preset, you can go into your brush menu (the one you access from the corner in the brushes tab) and create a new brush preset. This brush preset can be used with the eraser.
    I prefer to use tool presets because they include more information, but they do lose the flexibility of brush presets that way. I hope that helps!

    ReplyDelete
  26. Thank you very much dear Sir for sharing us your brush stuff and experiences!

    ReplyDelete
  27. Thank you so much for sharing this! This is a gamechanger! Thanks again for your generous share.

    ReplyDelete
  28. Anonymous11:21 PM

    6.66Mb - *Gasp* lol.

    Cheers, mate.
    Very kind of you.

    ReplyDelete
    Replies
    1. Go by the, uh, _other_ measurement of MB in this case. If it makes you more comfortable. :)

      Delete
  29. Thanks for sharing this. Your brushes are amazing :)

    ReplyDelete
  30. Hey Sam just curious if you ever ended up posting these brushes for cs6? cheers

    ReplyDelete
    Replies
    1. I have a CS6 set, but I haven't polished them enough to feel comfortable posting them yet. Maybe soon!

      Delete
  31. So I downloaded the file: Sam's Tool Presets.tpl Not sure what to do with them/how to access the brushes. Shouldnt the extension be .abr or a folder...I dunno, no matter where I put that .tpl file I can't seem to get it right. Can somebody help me? Apparently I'm a moron :D

    ReplyDelete
    Replies
    1. It's a toolset, which means it goes in the presets folder just like the brushes, but not in the brushes subfolder (tools instead). I've tell you exact location but it's different depending on whether you're using a mac or PC (and depending on which version of windows).

      Delete
    2. http://www.photoshopdaily.co.uk/tutorials/install-tool-presets/ shows where to put it for a mac.

      Delete
    3. Oh, and it won't show up in your brushes window. You need to open up your tool presets window to access these brushes.

      Delete
  32. Thanks for sharing useful brush! :)

    ReplyDelete
  33. This comment has been removed by the author.

    ReplyDelete
  34. Thanx
    welcom on free photoshpp online
    http://www.onlin-photoshop.org

    ReplyDelete
  35. Thank you for the photoshop tips! It's a lifetime of learning photoshop. I like your character art at the top, glad you are able to enjoy your career! I'll be experimenting with the different brushes. Sometimes I'm not sure what to do with one or the other, or they don't do what I want. I suppose I can just create my own too. Sometimes I end up with something unique, but that has to go into my portfolio. The client won't approve! ~Digital abstract in california

    ReplyDelete
  36. Immortall6:06 AM

    Thanks for your brushes!
    Did you post somewhere your CS6 brushes? Please :)

    ReplyDelete
